Sony's UPX-C100 SNAP-ID Digital Printing System is designed for passport and ID
photo applications. This versatile system includes a digital still camera and a
digital photo printer which are connected via a USB cable.
The printer
accommodates two different media sizes for the simple creation of Passports,
I.D. cards, event photos, and other applications. The 5 mega pixel digital
camera is simple to use and offers quick adjustments such as color and
frame changes. The camera also has "Auto Review" which allows the captured image
to be reviewed while still in Camera Mode (without having to switch to Playback
Mode). The UPX-C100 SNAP-ID system uses Sony's dye sublimation print technology
so the results will be long-lasting and professional.
Printing with the
UPX-C100 is a snap – there is no docking station – simply connect the USB cable
to the camera and press Print. The camera can be powered either via the included
AC power adaptor or 2 AA batteries.
Features and
Benefits
• Auto Review allows images to be reviewed in
Camera Mode.
• Easily adjust head & chin lines, or any of the preset
frames to customize a print.
• Easy color adjustment to change hue,
contrast, and tone.
• Three different print sizes and color/black &
white options.
• USB connectivity = fast data transfers.
Specifications
Camera:
• Resolution: 5 MP (effective)
• Data compression: JPEG
•
Memory: 16MB (internal)
• Image capacity:
FULL (2576 x 1932): 10 or more
images
HIGH (1280 x 960): 40 or more images
STD (832 x 624): 100 or more
images
HIGH-ID (1280 x 960): 40 or more images
STD-ID (832 x 624): 100
or more images
• Lens: f=5.7 to 17.1mm, 3 times
• Focus: Auto focus (0.8
m and over)
• Flash: Internal flash (GN6)
• LCD display: 2-inch TFT
color LCD (110K pixels)
• Interface: USB host port for the printer
• Power Supply: DC
In ( 5.0 V) or 2 AA batteries
• Dimensions: 3 7/8 x 2 5/8 x 1 5/16 inches
• Weight: Approx. 7 oz (without batteries)
• Printing method: Dye
Sublimation thermal transfer
Printer:
• Resolution: 403
dpi
• Gradations: 8 bits for yellow, magenta, and cyan
• Paper size
• UPC-X34: 3.5 x 4 inches
• UPC-X46: 4 x 6 inches
• Print size
•
UPC-X34: 2 7/8 x 3 3/4 inches
• UPC-X46: 3 7/8 x 5 7/8 inches, Full bleed: 4
x 6 inches
• Printing time (approximate)*
• UPC-X34: 65 seconds
•
UPC-X46: 100 seconds
• Paper tray capacity
• UPC-X34: 30 sheets
•
UPC-X46: 25 sheets
• Interface: USB
• Power requirements: AC 100 to 240
V
• Dimensions: 8 x 3 3/8 x 12 1/8 inches
• Weight: Approx. 5 lb 15 oz
*Excluding transfer and processing time
Click here for a Sony Paper Media Brochure
DOWNLOAD
(PDF 870Kb) |
